9PK Automotive Multi-V & Serpentine Belts

No.SMT-MVB-9PK

SUMATE 9PK automotive multi-V belts have nine longitudinal ribs and are available in 55 listed sizes from 9PK970 to 9PK4145. The range serves passenger cars, commercial vehicles, construction machinery, agricultural machinery, and other automotive accessory-drive applications.

Profile: PK
Number of ribs: 9
Listed size range: 9PK970–9PK4145
Fitment support: Belt code, OE number, vehicle or equipment details, and engine model

The listed sizes represent our current standard range. If your required 9PK code is not shown, send us the complete belt code, dimensions, and required quantity for production review. The rib count and length code alone are not sufficient to confirm fitment.

Get The Latest Quote

Description

9PK AUTOMOTIVE MULTI-V BELT RANGE

9PK Multi-V Belts in 55 Listed Sizes

SUMATE supplies 9PK multi-V belts for automotive and mobile-equipment accessory-drive systems. Each belt uses the PK rib profile and has nine longitudinal ribs. Available codes in this range extend from 9PK970 to 9PK4145, covering passenger-vehicle applications as well as belt-drive layouts used in commercial vehicles, construction machinery, and agricultural machinery.

In a code such as 9PK970, “9” identifies the number of ribs, “PK” identifies the rib profile, and the final number indicates the nominal reference length in millimetres. The complete code, OE number, pulley layout, and application information should be checked before purchase.

9Longitudinal ribs

PKRib profile

55Listed sizes

970–4145 mmReference-length range

Size coverage: The range includes 1 code below 1,000 mm, 20 codes between 1,000 and 1,999 mm, and 34 codes at 2,000 mm or above. This distribution provides a quick overview of the current standard range; final application matching still depends on the complete belt code and vehicle or equipment information.

Available 9PK Belt Codes

The table lists the standard 9PK codes currently included in our supply range. It is not a complete limit of our production capability. If your required 9PK size is not listed, send us the complete belt code, dimensions, application information, and required quantity. Our team will review production feasibility and confirm the specification, minimum order quantity, and lead time.

9PK belt codes and nominal reference lengths
Belt code	Length (mm)	Belt code	Length (mm)	Belt code	Length (mm)	Belt code	Length (mm)
9PK970	970	9PK1245	1245	9PK1250	1250	9PK1270	1270
9PK1290	1290	9PK1377	1377	9PK1380	1380	9PK1550	1550
9PK1570	1570	9PK1580	1580	9PK1590	1590	9PK1690	1690
9PK1725	1725	9PK1825	1825	9PK1885	1885	9PK1890	1890
9PK1900	1900	9PK1905	1905	9PK1920	1920	9PK1940	1940
9PK1960	1960	9PK2000	2000	9PK2005	2005	9PK2060	2060
9PK2100	2100	9PK2125	2125	9PK2140	2140	9PK2160	2160
9PK2200	2200	9PK2245	2245	9PK2246	2246	9PK2247	2247
9PK2248	2248	9PK2249	2249	9PK2250	2250	9PK2251	2251
9PK2252	2252	9PK2253	2253	9PK2254	2254	9PK2255	2255
9PK2256	2256	9PK2257	2257	9PK2258	2258	9PK2259	2259
9PK2261	2261	9PK2288	2288	9PK2289	2289	9PK2290	2290
9PK2291	2291	9PK2292	2292	9PK2618	2618	9PK2832	2832
9PK2833	2833	9PK2835	2835	9PK4145	4145

Typical Application Areas

Passenger-car accessory drives
Light and heavy commercial vehicles
Construction machinery
Agricultural machinery
Other vehicle and mobile-equipment drive systems

Application coverage varies by belt code. A listed size does not mean that it fits every vehicle or machine in these groups.

Information Needed for Matching

Complete belt code printed on the existing belt
OE or cross-reference number
Vehicle or equipment make and model
Model year and engine model
Required quantity and destination country

Our team uses this information to check the requested specification and reduce the risk of an incorrect match.

Ordering and Availability

In-stock products have no minimum order quantity. For specifications that are not in stock, the minimum order quantity is 15 belts per individual belt code. In-stock orders can generally be dispatched within 3–4 days. Non-stock orders normally require at least 7 days, with the final dispatch time depending on the specification and order quantity.

Send us the belt code, OE number, application details, and required quantity for a confirmed quotation. Unlisted 9PK sizes can also be reviewed for production based on the required dimensions, construction, and order quantity.
